RIGHT CRANKCASE COVER FOR HONDA XLR 250 BAJA 1992

STARTER MOTOR CLUTCH

COVER COMP., R. CRANKCASE

11330-KZ1-670 11330KZ1670

Contact

COVER COMP., OIL FILTER

11333-KZ1-670 11333KZ1670

Contact

PLATE, OIL SEAL SETTING

11334-KK0-000 11334KK0000

Contact

PIPE COMP., OIL PASS

11335-KV6-000 11335KV6000

Contact

RUBBER, OIL PASS PIPE

11338-KK0-000 11338KK0000

Not available

GASKET, R. CRANKCASE COVE

11394-KK0-000

11394-KK0-306

£15,24

Unit Price Incl. Tax

ELEMENT, OIL FILTER

15412-KF0-010

15410-KF0-305

£7,34

Unit Price Incl. Tax

RUBBER, FILTER

15413-MC8-000 15413MC8000

£3,84

Unit Price Incl. Tax

SPRING, OIL FILTER ELEMEN
SPRING, OIL FILTER ELEMENT SETTING

15414-KF0-000 15414KF0000

£4,27

Unit Price Incl. Tax

BOLT, FLANGE, 8X28

15532-KK0-770 15532KK0770

£5,52

Unit Price Incl. Tax

BOLT, FLANGE, 7X25

15533-KK0-000 15533KK0000

£5,41

Unit Price Incl. Tax

BOLT, FLANGE, 7X38

15533-KK0-770 15533KK0770

Contact

GAUGE, OIL LEVEL

15650-KT1-000 15650KT1000

Contact

LEVER COMP., CLUTCH

22810-KT1-000 22810KT1000

SPRING, CLUTCH LEVER

22815-KT1-000 22815KT1000

Contact

FOLLOWER, CAM

28271-428-000 28271428000

Not available

SPRING, FOLLOWER

28274-KK0-000 28274KK0000

Not available

SHAFT COMP., FOLLOWER

28280-KT1-000 28280KT1000

Contact

RECEIVER B, DECOMPRESSION

28287-KT1-000 28287KT1000

Contact

IGNITION PULSE GENERATOR ASSY.

30300-KZ9-000 30300KZ9000

Contact

BOLT, FLG, SOC, 6X28
BOLT, FLANGE SOCKET, 6X28

90092-KF0-000 90092KF0000

Not available

BOLT, FLANGE SOCKET, 6X40

90093-KF0-000 90093KF0000

£4,26

Unit Price Incl. Tax

BOLT, FLANGE SOCKET, 6X45

90093-MG3-000 90093MG3000

£4,38

Unit Price Incl. Tax

BOLT, FLG.SOC, 6X60
BOLT, FLANGE SOCKET, 6X60

90094-KG0-000 90094KG0000

Not available

NUT, U, 6MM

90301-MG3-000 90301MG3000

£6,83

Unit Price Incl. Tax

WASHER, SEALING, 7MM

90441-MC0-000 90441MC0000

£2,34

Unit Price Incl. Tax

WASHER C, 8MM

90475-703-000 90475703000

£1,19

Unit Price Incl. Tax

OIL SEAL, 12X22X5

91201-965-000 91201965000

£4,26

Unit Price Incl. Tax

OIL SEAL, 18X29X7
OIL SEAL, 18X29X7 (ARAI)

91202-KK0-003 91202KK0003

£4,42

Unit Price Incl. Tax

OIL SEAL, 18X29X7

91202-KK0-005

91202-KK0-003

£4,42

Unit Price Incl. Tax

OIL SEAL, 12X18X5 (ARAI)

91204-KK0-003 91204KK0003

£6,01

Unit Price Incl. Tax

O-RING, 54X2.4 (ARAI)

91302-KF0-003 91302KF0003

£4,75

Unit Price Incl. Tax

O-RING, 7X1.7

91303-KE7-003

91312-107-000

£4,14

Unit Price Incl. Tax

O-RING, 18X3 (ARAI)

91307-KF0-003 91307KF0003

£2,62

Unit Price Incl. Tax

O-RING, 9.8X1.9

91305-PE2-003 91305PE2003

£2,74

Unit Price Incl. Tax

PIN, DOWEL, 8X14
DOWEL PIN, 8X14

90704-KL4-000 90704KL4000

Contact

DOWEL PIN, 10X16

94301-10160 9430110160

£3,26

Unit Price Incl. Tax

CIRCLIP, EXTERNAL, 10MM

94510-10000 9451010000

£1,04

Unit Price Incl. Tax

BOLT, FLANGE SOCKET, 6X18

90072-MF5-860 90072MF5860

Contact

BOLT, FLANGE, 6X10

96001-0601000 960010601000

£1,43

Unit Price Incl. Tax

BOLT, FLANGE, 6X25

96001-0602507 960010602507

£1,43

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the RIGHT CRANKCASE COVER of your Honda XLR 250 BAJA of XL. Let us know if you have any questions.
