ALTERNATOR

CRANKCASE FOR HONDA XR 200 R 2002

CRANKSHAFT

CRANKCASE Honda MOTO 200 XR 2002 XR200R2
1
CRANKCASE COMP., R.

11100-KT0-684   11100KT0684

11100KT0684
Contact
2
GASKET, CRANK CASE

11191-KT0-710  

11191-KT0-711
 11191KT0710

Unit Price Incl. Tax

3
CRANKCASE COMP., L.

11200-KT0-680   11200KT0680

11200KT0680
Contact
4
CAP, TAPPET ADJUSTING HOL
CAP, TAPPET ADJUSTING HOLE

12361-383-000   12361383000

12361383000

Unit Price Incl. Tax

5
SCREEN, OIL FILTER
SCREEN, OIL FILTER

15421-107-000   15421107000

15421107000

Unit Price Incl. Tax

6
SPRING, OIL FILTER SCREEN
SPRING, OIL FILTER SCREEN

15426-107-000   15426107000

15426107000

Unit Price Incl. Tax

7
HOLDER, CLUTCH WIRE

22838-437-000  

22838-437-010
 22838437000

Unit Price Incl. Tax

8
BOLT A, CYLIN.STUD
BOLT A, CYLINDER STUD

90031-427-010   90031427010

90031427010
Not available
9
BOLT B, CYLIN.HEAD
BOLT B, CYLINDER STUD

90032-427-010   90032427010

90032427010
Not available
10
PIN A, DOWEL, 10X14

90703-HC4-000  

94301-10140
 90703HC4000

Unit Price Incl. Tax

11
OIL SEAL, 14X28X7 (ARAI)

91206-286-013   91206286013

91206286013
12
O-RING, 35X3 (ARAI)

91303-107-000  

91303-KK3-830
 91303107000

Unit Price Incl. Tax

13
BOLT, HEX., 6X60

92101-060600A   92101060600A

92101060600A

Unit Price Incl. Tax

14
BOLT, FLANGE, 6X50
BOLT, FLANGE, 6X50

96001-0605000   960010605000

960010605000

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CRANKCASE of your Honda XR 200 R of XR. Let us know if you have any questions.

Genuine parts for Honda 2002 XR 200 R

Engine Frame

Honda 2002 XR 200 R

All the Honda 200 XR 2002 genuine spare parts

Color code : R134
200 XR 2002 XR200R2
Color code : R134

XR 200 R

Honda XR

Displacement: 200 cc
Year: 2002
Model code XR200R2
Color: R134
Drapeau CANADA
Canada

Genuine maintenance parts

Spark Plug
Drain plug gasket

Technical specifications

Engine oil quantity:
1,0 Liters
