KICK STARTER ARM - BRAKE PEDAL - GEAR LEVER FOR HONDA XR 200 R 2000

FOOTREST

(1) 24700-KT0-770

PEDAL COMP., CHANGE

(2) 28241-KT0-670

JOINT, KICK ARM

(3) 28293-124-000

CLIP, KICK STARTER ARM

(4) 28300-KT0-670

ARM ASSY., KICK STARTER

(5) 28321-427-770

PIN, KICK STARTER

(6) 28333-124-000

SPRING, KICK STARTER STOP
SPRING, KICK STARTER STOPPER

(7) 43451-KT0-000

OBSOLETE
ROD, RR. BRAKE

(8) 43459-434-000

NUT, BRAKE ADJUSTING

(9) 43472-KB9-750

SPRING A, BRAKE ROD

(10) 46500-KT0-670

PEDAL COMP., BRAKE

(11) 46513-KT0-670

SPRING SET, BRAKE PEDAL

(12) 46515-KL4-000

TUBE, BRAKE PEDAL SPRING

(13) 46525-KK0-003

DUST SEAL, 17X20X2.5

(14) 46526-KT0-680

PROTECTOR, MIDDLE ARM

(15) 50530-KT0-690

BAR, SIDE STAND

(16) 50535-KN5-670

SPRING, SIDE STAND

(17) 90101-KK0-000

SHAFT.BRAKE PIVOT
SHAFT, RR. BRAKE PIVOT

(18) 90108-KG0-000

SCREW,STAND PIVOT
SCREW, SIDE STAND PIVOT

(19) 90304-GE8-003

NUT, U, 10MM (FUSE RASHI)
NUT, U, 10MM

(20) 92201-060250A

BOLT, HEX., 6X25

(21) 94001-062000S

NUT, HEX., 6MM

(22) 94201-20120

PIN, SPLIT, 2.0X12

(23) 95015-32001

JOINT B, BRAKE ARM

(24) 95015-53000

PIN C, JOINT

(25) 95701-0802500

BOLT, FLANGE, 8X25

(26) 96211-08000

BALL, STEEL, #8 (1/4)

(27) 96300-0802507

BOLT, FLANGE, 8X25

(28) 96300-0602007

BOLT,FLANGE,DR,6X
BOLT, FLANGE, 6X20

	Part number	Description	Qty
# 1	24700-KT0-770 24700KT0770 24700KT0770	PEDAL COMP., CHANGE	Contact	£0,00
# 2	28241-KT0-670 28241KT0670 28241KT0670	JOINT, KICK ARM	Contact	£0,00
# 3	28293-124-000 28293124000 28293124000	CLIP, KICK STARTER ARM	£1,34
# 4	28300-KT0-670 28300KT0670 28300KT0670	ARM ASSY., KICK STARTER	Contact	£0,00
# 5	28321-427-770 28321427770 28321427770	PIN, KICK STARTER	£5,59
# 6	28333-124-000 28333124000 28333124000	SPRING, KICK STARTER STOP SPRING, KICK STARTER STOPPER	£2,10
# 7	43451-KT0-000 43451KT0000 43451KT0000	OBSOLETE ROD, RR. BRAKE	Contact	£0,00
# 8	43459-434-000 43459434000 43459434000	NUT, BRAKE ADJUSTING	£8,92
# 9	43472-KB9-750 43472KB9750 43472KB9750	SPRING A, BRAKE ROD	£3,07
# 10	46500-KT0-670 46500KT0670 46500KT0670	PEDAL COMP., BRAKE	Contact	£0,00
# 11	46513-KT0-670 46513KT0670 46513KT0670	SPRING SET, BRAKE PEDAL	£9,05
# 12	46515-KL4-000 46515KL4000 46515KL4000	TUBE, BRAKE PEDAL SPRING	£4,62
# 13	46525-KK0-003 46525KK0003 46525KK0003	DUST SEAL, 17X20X2.5	£7,50
# 14	46526-KT0-680 46526KT0680 46526KT0680	PROTECTOR, MIDDLE ARM	£12,40
# 15	50530-KT0-690 50530KT0690 50530KT0690	BAR, SIDE STAND	Contact	£0,00
# 16	50535-KN5-670 50535KN5670 50535KN5670	SPRING, SIDE STAND	£7,57
# 17	90101-KK0-000 90101KK0000 90101KK0000	SHAFT.BRAKE PIVOT SHAFT, RR. BRAKE PIVOT	£11,68
# 18	90108-KG0-000 90108KG0000 90108KG0000	SCREW, STAND PIVOT SCREW, SIDE STAND PIVOT	£6,53
# 19	90304-GE8-003 90304GE8003 90304GE8003	NUT, U, 10MM (FUSE RASHI) NUT, U, 10MM	£3,70
# 20	92201-060250A 92201060250A 92201060250A	BOLT, HEX., 6X25	£1,19
# 21	94001-060000S 94001-062000S 94001060000S	NUT, HEX., 6MM	£2,88
# 22	94201-20120 9420120120 9420120120	PIN, SPLIT, 2.0X12	£0,94
# 23	95015-32001 9501532001 9501532001	JOINT B, BRAKE ARM	£1,80
# 24	95015-53000 9501553000 9501553000	PIN C, JOINT	£3,50
# 25	95701-0802500 957010802500 957010802500	BOLT, FLANGE, 8X25	£1,80
# 26	96211-08000 9621108000 9621108000	BALL, STEEL, #8 (1/4)	£0,32
# 27	96300-0802507 963000802507 963000802507	BOLT, FLANGE, 8X25	£1,96
# 28	96500-0602007 96300-0602007 965000602007	BOLT, FLANGE, DR, 6X BOLT, FLANGE, 6X20	£1,38

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the KICK STARTER ARM - BRAKE PEDAL - GEAR LEVER of your Honda XR 200 R of XR. Let us know if you have any questions.
