KICKSTARTER AXLE FOR HONDA TLM 200 1987

LEFT HAND CRANKCASE COVER - ALTERNATOR (1)

(1) 28211-KE1-000

PINION, KICK STARTER (21T)

(2) 28221-KE1-000

RATCHET, KICK STARTER

(3) 28223-KE1-000

SPRING, RATCHET

(4) 28225-KE1-000

PLATE, KICK STARTER

(5) 28231-KE1-000

GEAR, STARTER IDLE (26T)

(6) 28232-KE1-000

BUSH, STARTER IDLE GEAR

(7) 28251-KE1-000

SPINDLE, KICK STARTER

(8) 28281-KE1-000

SPRING, KICK RETURN

(9) 28282-KE1-000

COLLAR, KICK SPRING

(10) 90031-KE1-000

BOLT, KNOCK, 6MM

(11) 90453-235-000

WASHER, THRUST, 16MM

(12) 90459-360-000

WASHER, THRUST, 12.5MM

(13) 95701-0601600

BOLT, FLANGE, 6X16

	Part number	Description	Qty
# 1	28211-KE1-000 28211KE1000 28211KE1000	PINION, KICK STARTER (21T)	Contact	£0,00
# 2	28221-KE1-000 28221KE1000 28221KE1000	RATCHET, KICK STARTER	Contact	£0,00
# 3	28223-KE1-000 28223KE1000 28223KE1000	SPRING, RATCHET	Contact	£0,00
# 4	28225-KE1-000 28225KE1000 28225KE1000	PLATE, KICK STARTER	Contact	£0,00
# 5	28231-KE1-000 28231KE1000 28231KE1000	GEAR, STARTER IDLE (26T)	Contact	£0,00
# 6	28232-KE1-000 28232KE1000 28232KE1000	BUSH, STARTER IDLE GEAR	Contact	£0,00
# 7	28251-KE1-000 28251KE1000 28251KE1000	SPINDLE, KICK STARTER	Contact	£0,00
# 8	28281-KE1-000 28281KE1000 28281KE1000	SPRING, KICK RETURN	Not available	£0,00
# 9	28282-KE1-000 28282KE1000 28282KE1000	COLLAR, KICK SPRING	Contact	£0,00
# 10	90031-KE1-000 90031KE1000 90031KE1000	BOLT, KNOCK, 6MM	Contact	£0,00
# 11	90453-235-000 90453235000 90453235000	WASHER, THRUST, 16MM	£2,28
# 12	90459-360-000 90459360000 90459360000	WASHER, THRUST, 12.5MM	£2,71
# 13	95700-0601600 95701-0601600 957000601600	BOLT, FLANGE, 6X16	£1,19

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the KICKSTARTER AXLE of your Honda TLM 200 of TRIAL. Let us know if you have any questions.
