CRANKSHAFT

GEARBOX FOR HONDA CROSS CUB 110 KUMAMON 2022

GEARSHIFT DRUM

Item numbers

MAINSHAFT (14T)

23211-K2N-C00 23211K2NC00

Contact

COUNTERSHAFT

23221-K88-J51 23221K88J51

Contact

BUSH, 15MM

23415-K2N-C00 23415K2NC00

Contact

GEAR, COUNTERSHAFT LOW (37T) (44T)

23421-K2N-C00 23421K2NC00

Contact

BUSH, 17MM

23422-K1M-T00 23422K1MT00

Contact

GEAR, MAINSHAFT SECOND (16T) (18T)

23431-K2N-C00 23431K2NC00

Contact

BUSH, 12MM BUSH, 12MM
--- BAGUE, 12MM

23432-K1M-T00 23432K1MT00

£6,29

Unit Price Incl. Tax

GEAR, COUNTERSHAFT SECOND (33T)

23441-K2N-C00 23441K2NC00

Contact

GEAR, MAINSHAFT THIRD (20T) (21T)

23451-K2N-C00 23451K2NC00

Contact

BUSH, 20MM

23452-K1M-T00 23452K1MT00

£8,70

Unit Price Incl. Tax

GEAR, COUNTERSHAFT THIRD (28T)

23461-K2N-C00 23461K2NC00

Contact

GEAR, MAINSHAFT FOURTH (28T)

23471-K2N-C00 23471K2NC00

Contact

GEAR, COUNTERSHAFT FOURTH (30T)

23481-K2N-C00 23481K2NC00

Contact

SPROCKET, DRIVE (14T)
SPROCKET, DRIVE (12T) (14T)

23801-GF6-000 23801GF6000

£16,92

Unit Price Incl. Tax

PLATE, FIXING
PLATE, SETTING

23802-KVR-C00 23802KVRC00

£0,71

Unit Price Incl. Tax

COLLAR, LOCK PLATE

23911-K1M-T00 23911K1MT00

£2,60

Unit Price Incl. Tax

SPRING, CHANGE FRICTION

24305-K1M-T00 24305K1MT00

£3,05

Unit Price Incl. Tax

PLATE, DRUM LOCK

24306-K1M-T00 24306K1MT00

Contact

WASHER, 6.2X19X2.3 WASHER, 6.2X19X2.3
--- RONDELLE, 6.2X19X2.3

90407-KWW-740 90407KWW740

£2,60

Unit Price Incl. Tax

WASHER, 6.2X19X2.3 WASHER, 6.2X19X2.3
--- RONDELLE, 6.2X19X2.3

90407-KWW-740 90407KWW740

£2,60

Unit Price Incl. Tax

WASHER, THRUST, 15MM

90412-187-000 90412187000

£3,41

Unit Price Incl. Tax

WASHER, SPECIAL, 15MM WASHER, SPECIAL, 15MM
--- RONDELLE SPECIALE, 15MM

90412-K56-N00 90412K56N00

£2,75

Unit Price Incl. Tax

WASHER, SPL 12MM

90452-KGH-900

90452-KPH-C00

£1,37

Unit Price Incl. Tax

WASHER, SPLINE, 17X23X1.6

90452-KRM-840 90452KRM840

£6,17

Unit Price Incl. Tax

WASHER, SPLINE, 20MM

90453-KRM-840 90453KRM840

£2,51

Unit Price Incl. Tax

WASHER, THRUST, 12MM

90459-107-000 90459107000

£2,45

Unit Price Incl. Tax

CIRCLIP, 17MM

90601-KRM-840 90601KRM840

£1,01

Unit Price Incl. Tax

SET RING, 20MM

90605-KVS-900 90605KVS900

£1,00

Unit Price Incl. Tax

BEARING, RADIAL BALL, 15X BEARING, RADIAL BALL, 15X
--- ROULEMENT A BILLES RADIAL, 15X42X11

91003-K1M-T01 91003K1MT01

£16,54

Unit Price Incl. Tax

BEARING, RADIAL BALL, 600
BEARING, RADIAL BALL, 6001

91013-KZV-J01 91013KZVJ01

£24,89

Unit Price Incl. Tax

BEARING, RADIAL BALL, 620
BEARING, RADIAL BALL, 6203

91015-KZV-J01 91015KZVJ01

£24,89

Unit Price Incl. Tax

BEARING, RADIAL BALL, 620
BEARING, RADIAL BALL, 6203

91015-KZV-J01 91015KZVJ01

£24,89

Unit Price Incl. Tax

OIL SEAL, 17X30X5 (ARAI)

91204-KPH-901 91204KPH901

£4,18

Unit Price Incl. Tax

BOLT, HEX., 6X10

92101-060100A 92101060100A

BOLT, FLANGE, 6X14

95701-0601400 957010601400

£0,86

Unit Price Incl. Tax

BOLT, FLANGE, 6X14

95701-0601400 957010601400

£0,86

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the GEARBOX of your Honda CROSS CUB 110 KUMAMON of CUB. Let us know if you have any questions.
